3 Sets Total 3.3MW Stainless Steel Tube V-type Dry Cooler for Data Center Cooling
- Model
- V-type Dry Cooler
Item specifics
- Core Component
- Finned Tube Heat Exchanger
- Tube Diameter
- 7mm, 9.52mm, 12.7mm, 15.88mm
- Casing Material
- Galvanized Sheet, Aluminium, Stainless Steel
- Tube Material
- Copper, Stainless Steel
- Fin Material
- Aluminum, Copper, Stainless Steel
Review
Description
3.3MW Stainless Steel Tube V-type Dry Cooler for Data Center Cooling
This Customized 6 Rows 60 Holes V-type Dry Cooler with 18 AC Fans is provided for Data Center Cooling.
The core construction uses 5/8" 15.88*0.65mm Stainless Steel Tubes and 0.12mm Hydrophilic Corrugated Aluminum Fins (FPI 2.1mm). Additionally, the Frames are manufactured out of 2.0mm thick Painted Steel Plate, the mounting brackets and wind panels are constructed using 3.0mm thick outdoor Painted Steel Plate.
- Specifications can be tailored to suit each application, with different materials, sizes, noises and cooling mediums available.
