5/8W Copper Tube Flat-type Dry Cooler
- Model
- BY-H-GLQ
Item specifics
- Core Component
- Finned Tube Heat Exchanger
- Tube Diameter
- 7mm, 9.52mm, 12.7mm, 15.88mm
- Casing Material
- Galvanized Sheet, Aluminium, Stainless Steel
- Tube Material
- Copper, Stainless Steel
- Fin Material
- Aluminum, Copper, Stainless Steel
Review
Description
5/8W Copper Tube Flat-type Dry Cooler
This 6 Rows 60 Holes Flat-type Dry Cooler with 4 EBM EC Fans is provided for Hotel Cooling.
The core construction uses 5/8" 15.88*0.5mm Copper Tubes and 0.12mm Acrylic Anticorrosive Hydrophilic Aluminum Fins (FPI 2.1mm). Additionally, the Frames are manufactured out of 1.2mm 304 stainless steel.
- Specifications can be tailored to suit each application, with different materials, sizes, noises and cooling mediums available.
